Bilstein

Bilstein 24-233354 B8 5100 - Suspension Shock Absorber

Bilstein 24-233354 B8 5100 - Suspension Shock Absorber

Regular price $123.00 USD
Regular price Sale price $123.00 USD
Mechanic Division pricing available
Sale Sold out
Shipping calculated at checkout.

10 in stock

Quantity
Description & Features

Bilstein 24-233354 B8 5100 - Suspension Shock Absorber

Bilstein B8 5100 shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

  • 46mm monotube design ensures consistent, fade-free performance in all conditions
  • Patented digressive valving instantly reacts to changing surface conditions
  • Vehicle specific tuning
Specifications
Collapsed Length (IN) 15.89
Extended Length (IN) 25.43
Lower Mount Type Eye 14.1mm
Internal Design Monotube
Collapsed Length (MM) 403.5
Reservoir No
Piston Diameter 46mm
Body Design Smooth Body (Non-coilover)
Extended Length (MM) 645.9
Stroke/Travel Length (IN) 9.54
Finish Zinc Plated
Upper Mount Type Stem
Stroke/Travel Length (mm) 242.3
Series B8 5100
Boot Included Black Bellows
Adjustable Damping Non-Adjustable
Spring Seat Included No
Shaft Diameter 14mm
Segment Light Truck
Packaging Information

Weight: 6 lbs
Dimensions: 26.8 x 2.95 x 2.95 IN

Safety

WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov

For more information visit www.P65Warnings.ca.gov

⚠ Fitment Notes
  • Fits non-Off Road Package Trucks with 0-2" Rear Lift; Fits factory Off Road Package Trucks with 0-1" Rear Lift; Without Air Suspension
  • Fits non-Off Road Package Trucks with 0-2" Rear Lift; Fits factory Off Road Package Trucks with 0-1" Rear Lift; Without Air Leveling Suspension
  • Fits Trucks without factory Off Road Package and with 0-1" Rear Lift; Without Air Leveling Suspension
  • Fits Trucks without factory Off Road Package and with 0-1" Rear Lift; Without Air Suspension
  • Fits Trucks with 0-1" Rear Lift; Without Air Suspension

Vehicle Fitment

  • 2019-2026 Ram 1500 Big Horn — Rear
  • 2026 Ram 1500 Express — Rear
  • 2019-2024 Ram 1500 HFE — Rear
  • 2019-2026 Ram 1500 Laramie — Rear
  • 2019-2020 Ram 1500 Laramie Longhorn — Rear
  • 2021-2024 Ram 1500 Limited Longhorn — Rear
  • 2019-2026 Ram 1500 Lone Star — Rear
  • 2019-2026 Ram 1500 Rebel — Rear
  • 2019-2026 Ram 1500 Tradesman — Rear
  • 2025 Ram 1500 Tradesman HFE — Rear
  • 2025-2026 Ram 1500 Warlock — Rear
