Bilstein 24-337069 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber
Bilstein 24-337069 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber
10 in stock
Couldn't load pickup availability
Description & Features
Bilstein 24-337069 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber
Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
- Adjustable spring seat offers 0-2.75in of lift, depending on the application
Specifications
| Stroke/Travel Length (IN) | 4.39 |
| Upper Mount Type | Stem |
| Stroke/Travel Length (mm) | 111.5 |
| Internal Design | Monotube |
| Body Design | Snap Ring Grooved Body (Coilover) |
| Boot Included | No |
| Reservoir | No |
| Spring Seat Included | Yes |
| Collapsed Length (IN) | 17.58 |
| Segment | Light Truck |
| Extended Length (IN) | 21.97 |
| Lower Mount Type | Bar Pin |
| Finish | Zinc Plated |
| Extended Length (MM) | 558.0 |
| Adjustable Damping | Non-Adjustable |
| Series | B8 5100 (Ride Height Adjustable) |
| Collapsed Length (MM) | 446.6 |
| Piston Diameter | 46mm |
| Shaft Diameter | 18mm |
Packaging Information
Weight: 8.81 lbs
Dimensions: 26.8 x 4.15 x 4.15 IN
Safety
WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
For more information visit www.P65Warnings.ca.gov
⚠ Fitment Notes
- Provides 0-1.1" Front Lift
Share
Vehicle Fitment
Vehicle Fitment
- 2019-2026 Chevrolet Silverado 1500 Custom Trail Boss — Front
- 2019-2026 Chevrolet Silverado 1500 LT Trail Boss — Front
- 2022 Chevrolet Silverado 1500 LTD Custom Trail Boss — Front
- 2022 Chevrolet Silverado 1500 LTD LT Trail Boss — Front
- 2019-2026 GMC Sierra 1500 AT4 — Front
- 2022 GMC Sierra 1500 Limited AT4 — Front
