Bilstein

Bilstein 25-302257 B8 8100 (DSA) - Suspension Shock Absorber

Bilstein 25-302257 B8 8100 (DSA) - Suspension Shock Absorber

Regular price $801.00 USD
Regular price Sale price $801.00 USD
Sale Sold out
Shipping calculated at checkout.

10 in stock

Quantity
Description & Features

Bilstein 25-302257 B8 8100 (DSA) - Suspension Shock Absorber

The Bilstein B8 8100 (DSA) reservoir shock absorber is an adjustable large bore 60mm (2.65" OD) direct fit solution for lifted trucks and SUVs. Constructed from aerospace quality billet components, the large 60mm ID shock body offers a higher oil volume capacity to control heat while tackling rough road surfaces over long distances. Click adjuster knobs allow easy and precise Dual Speed Adjustment of both low and high speed compression to tailor your ride to any surface. Each B8 8100 (DSA) offers a unique remote or piggyback reservoir solution for an easy, hassle free installation. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. The large 60mm piston design offers more comfort and control in all driving conditions. The Bilstein B8 8100 (DSA) will allow you to tame the terrain in comfort.

  • 60mm large bore digressive piston offers a greater range of tunability and delivers exceptional comfort without sacrificing control
  • Direct fit for an easy installation
  • Click adjuster knobs allow easy and precise Dual Speed Adjustment of both low and high speed compression to tailor your ride to any surface
Specifications
Segment Light Truck
Boot Included No
Extended Length (IN) 24.77
Lower Mount Type Eye 14.1mm
Finish EVO Grey
Extended Length (MM) 629.2
Series B8 8100 (DSA)
Body Design Smooth Body (Non-Coilover)
Collapsed Length (MM) 425.5
Piston Diameter 60mm
Shaft Diameter 18mm
Adjustable Damping Double Adjustable Compression with Click Adjuster Knobs
Upper Mount Type Stem
Internal Design Monotube
Reservoir Yes
Spring Seat Included No
Collapsed Length (IN) 16.75
Packaging Information

Weight: 20 lbs
Dimensions: 40.5 x 11.75 x 6.75 IN

Safety

WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov

For more information visit www.P65Warnings.ca.gov

Warranty

24 Month Warranty

⚠ Fitment Notes
  • Fits Vehicles With 0-1" Rear Lift; Without Air Leveling Suspension

Vehicle Fitment

  • 2019-2026 Ram 2500 Big Horn — Rear Left
  • 2026 Ram 2500 Black Express — Rear Left
  • 2019-2026 Ram 2500 Laramie — Rear Left
  • 2019-2021 Ram 2500 Laramie Longhorn — Rear Left
  • 2019-2026 Ram 2500 Limited — Rear Left
  • 2021-2026 Ram 2500 Limited Longhorn — Rear Left
  • 2019-2026 Ram 2500 Lone Star — Rear Left
  • 2023-2026 Ram 2500 Rebel — Rear Left
  • 2019-2026 Ram 2500 Tradesman — Rear Left
  • 2026 Ram 2500 Warlock — Rear Left
