Bilstein
Bilstein 25-331905 B8 5160 - Suspension Shock Absorber
Bilstein 25-331905 B8 5160 - Suspension Shock Absorber
10 in stock
Couldn't load pickup availability
Description & Features
Bilstein 25-331905 B8 5160 - Suspension Shock Absorber
Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control
- Remote reservoir increases shock oil capacity for greater heat dissipation
Specifications
| Segment | Light Truck |
| Extended Length (IN) | 28.19 |
| Stroke/Travel Length (IN) | 9.53 |
| Boot Included | No |
| Lower Mount Type | Eye 14.4mm |
| Finish | Zinc Plated |
| Upper Mount Type | Stem |
| Stroke/Travel Length (mm) | 242.1 |
| Extended Length (MM) | 716.0 |
| Collapsed Length (MM) | 474.0 |
| Internal Design | Monotube |
| Billet Reservoir Clamp Included | Yes |
| Series | B8 5160 |
| Body Design | Smooth Body (Non-Coilover) |
| Adjustable Damping | Non-Adjustable |
| Reservoir | Yes |
| Spring Seat Included | No |
| Piston Diameter | 46mm |
| Collapsed Length (IN) | 18.66 |
| Shaft Diameter | 14mm |
Packaging Information
Weight: 10 lbs
Dimensions: 26.8 x 4.15 x 4.15 IN
Safety
WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
For more information visit www.P65Warnings.ca.gov
Warranty
24 Month Warranty
⚠ Fitment Notes
- Fits Vehicles With 4" Rear Lift; Without Air Leveling Suspension
Share
Vehicle Fitment
Vehicle Fitment
- 2014-2026 Ram 2500 Big Horn — Rear
- 2026 Ram 2500 Black Express — Rear
- 2014-2026 Ram 2500 Laramie — Rear
- 2014-2015 Ram 2500 Laramie Limited — Rear
- 2014-2021 Ram 2500 Laramie Longhorn — Rear
- 2016-2026 Ram 2500 Limited — Rear
- 2021-2026 Ram 2500 Limited Longhorn — Rear
- 2014-2015 Ram 2500 Lone Star — Rear
- 2019-2026 Ram 2500 Lone Star — Rear
- 2014-2016 Ram 2500 Outdoorsman — Rear
- 2023-2026 Ram 2500 Rebel — Rear
- 2014-2018 Ram 2500 SLT — Rear
- 2014-2026 Ram 2500 Tradesman — Rear
- 2026 Ram 2500 Warlock — Rear
