Hella
Hella 002768082 Disc Type Low-Tone, 12 V, 335 Hz with Bracket
Hella 002768082 Disc Type Low-Tone, 12 V, 335 Hz with Bracket
Regular price
$23.20 USD
Regular price
Sale price
$23.20 USD
⬡Mechanic Division pricing available
Shipping calculated at checkout.
Low stock: 2 left
Quantity
Couldn't load pickup availability
Description & Features
Hella 002768082 Disc Type Low-Tone, 12 V, 335 Hz with Bracket
Make your presence known with the HELLA Horn. Designed for loud, clear sound output, it ensures you’re heard in any situation for added safety. Built tough to withstand harsh conditions, this horn delivers reliable performance and easy installation. Trust HELLA for durable, high-quality components that keep you safe on the road.
- Enhances road safety by emitting a 335 Hz tone, providing clear and audible alerts in all conditions.
- Delivers maximum awareness with a volume output ranging from 108 dB(A) to 118 dB(A), ensuring audibility.
- Ensures long-term reliability with robust construction engineered to withstand vibration and harsh conditions.
- Facilitates fast identification and installation with concise short codes, streamlining maintenance and replacement.
- Designed for universal compatibility, this part fits most modern vehicles, simplifying the installation process.
Specifications
| Voltage | 12.00 |
| Connector Quantity | 1 |
| Terminal Quantity | 2 |
| Mounting Bracket Included | Yes |
| Color | Black / Gray |
| Terminal Type | Blade |
| Mount Type | Bracket Mounting |
| Mounting Hardware Included | Yes |
| Decibel Rating | 116.00 |
| Diameter [cm] | 11.2 |
| Single Includes | (1) Low-Tone Disc Horn, Mounting Brackets, Step-by-Step Mounting Instructions |
| Includes | (1) Universal Mounting Bracket |
| Sound Level [dB(A)] | 116 |
| Grade Type | Standard Replacement |
| Depth [in] | 2.09 |
| California Proposition 65 Required | No |
| Supplementary Article/Supplementary Info 2 | with E Quality Seal |
| Quantity | 1 |
| Assy/Disassy by Qualified Personnel Required! | . |
| IP Rating | X4K |
| Temperature range to [°F] | 140 |
| Overall Height [in] | 5.08 |
| Measurements [cm] | 5.3 x 12.9 |
| Temperature range to [°C] | 60 |
| Depth [mm] | 53 |
| Power consumption [A] | 6 |
| Housing Color | Gray |
| ECE Regulation | R28 |
| Frequency range from [Hz] | 335 |
| Frequency Range [Hz] | 335 |
| Mounting Type | with 6.3 mm Blade Terminal Contacts, Open |
| Temperature range from [°F] | -40 |
| Temperature range from [°C] | -40 |
| Signal | Low Tone |
| Overall Height [mm] | 129 |
| Test Mark | ECE |
| Registration Type | ECE Approved |
| Voltage [VDC] | 12 |
| Homologation | ECE-R28 |
| Operating Mode | Electric |
| Bracket | M10 Mounting Screw |
| Diameter [mm] | 112 |
| Diameter [in] | 4.41 |
| Wattage [W] | 80 |
Packaging Information
Weight: 0.7683 lbs
Dimensions: 4.9213 x 2.4016 x 5.4331 IN
Warranty
12 Month Warranty
