Mishimoto MMCLAMP-35 T-Bolt Clamp, Stainless-Steel, 3.39in (86 mm) to 3.7 in (94.01 mm)
Mishimoto MMCLAMP-35 T-Bolt Clamp, Stainless-Steel, 3.39in (86 mm) to 3.7 in (94.01 mm)
Low stock: 3 left
Couldn't load pickup availability
Description & Features
Mishimoto MMCLAMP-35 T-Bolt Clamp, Stainless-Steel, 3.39in (86 mm) to 3.7 in (94.01 mm)
Mishimoto T-bolt clamps are a great solution for projects that need more clamping force than a standard worm gear clamp can provide. Built from the same stainless steel as our worm gear clamps, these T-bolt clamps are as durable as they are strong. The T-bolt design provides superior clamping power while the included locking nut keeps the clamp tight against any vibration. Available in a wide range of sizes, these clamps are an excellent choice for a variety of applications. Like all Mishimoto clamps, this T-bolt clamp is backed by our Mishimoto Lifetime Warranty.
- Securely clamps pipes, couplers, and hoses with an outer diameter from 3.39" (86 mm) to 3.7" (94.01 mm)
- T-bolt design provides a strong and secure grip
- Included self-locking nut prevents loosening with movement and vibration
Specifications
| Band Width | 0.75 |
| Color | Silver |
| Finish | Plain |
| Grade Type | Premium |
| Material | Stainless Steel |
| Maximum Diameter | 3.7 |
| Minimum Diameter | 3.38 |
| Recommended Torque | 27 |
| Reusable | Yes |
| SAE Size | 60 |
| SAE Type | F |
| Size | 3.5 |
| Spring Material | Steel |
| Type | T-Bolt |
| TechSpec Clamp Style | T-Bolt Clamp |
| TechSpec Minimum Clamp Diameter (in) | 3.38 |
| TechSpec Maximum Clamp Diameter (in) | 3.7 |
| TechSpec Material | Stainless Steel |
| TechSpec Includes | (1) Mishimoto Stainless Steel T-Bolt Clamp--Mishimoto Lifetime Warranty |
| TechSpec Recommended Tightening Torque | 27 in-lbs (3 NM) |
| TechSpec Band Width (in) | 0.75 |
| TechSpec SAE Number | N/A |
| TechSpec Note | N/A |
| SellingPoint01 | Securely clamps pipes, couplers, and hoses with an outer diameter from 3.39" (86 mm) to 3.7" (94.01 mm) |
| SellingPoint02 | T-bolt design provides a strong and secure grip |
| SellingPoint03 | Included self-locking nut prevents loosening with movement and vibration |
| SellingPoint04 | Stainless steel construction resists corrosion longer than zinc-plated clamps |
| SellingPoint05 | Optional wear-resistant titanium nitride gold coating provides unique engine bay styling |
| SellingPoint06 | Clamps sold individually |
| SellingPoint07 | Mishimoto Lifetime Warranty |
| SellingPoint08 | N/A |
| SellingPoint09 | N/A |
| SellingPoint10 | N/A |
| SellingPoint11 | N/A |
| SellingPoint12 | N/A |
| SellingPoint13 | N/A |
| SellingPoint14 | N/A |
| SellingPoint15 | N/A |
| Install Difficulty | 1 |
| OptionLabel | Stainless Steel |
Packaging Information
Weight: 0.17 lbs
Dimensions: 5.5 x 5.5 x 1 IN
