Mishimoto

Mishimoto MMRAD-RAM-13 Performance Aluminum Radiator, fits Dodge 6.7L Cummins 2013-2018

$1,024.95 USD

Sale Sold out

Shipping calculated at checkout.

10 in stock

Description & Features

Mishimoto MMRAD-RAM-13 Performance Aluminum Radiator, fits Dodge 6.7L Cummins 2013-2018

The legendary reliability and power of the 6.7L Cummins equipped Dodge Ram has solidified it as one of the most popular trucks in the world for getting work done. But every legend has its weakness, and for the Dodge Ram, the stock radiator is one of them.The plastic end-tanks of the stock Ram radiator are prone to cracking and leaks over time. Add the increased stress and heat created by power-adding modifications and you have a recipe for disaster. But that's where Mishimoto can help.Our new 2013-2018 Ram 2500 / 3500 radiator is the ideal upgrade for any workhorse Cummins powered Ram. With a fully-aluminum, TIG-welded construction, this radiator is built as tough as your truck. A 63-percent increase in coolant capacity, and 41-percent larger surface area mean you can pile on the power and never worry about the heat.As with all of our products, this radiator is backed up by Mishimoto's Lifetime Warranty. Doesn't your Ram deserve a radiator worthy of legend?

Increases coolant capacity by 63-percent and surface area by 41-percent to maximize cooling
Durable fully aluminum construction with TIG-welded end tanks and fittings
Features a 2-in thick, three-row core for efficient cooling under high loads

Specifications

Inlet Diameter	1.61
Outlet Diameter	1.61
Core Thickness	1.88
Overall Width	2.75
Overall Height	22
Core Height	22
Core Length	26.75
Core Row Quantity	3
Overall Length	33.5
Core Material	Aluminum
Outlet Location	Bottom Right
Down Flow Or Cross Flow Type	Cross Flow
Drain Plug Thread Size	M12 - 1.5
Transmission Oil Cooler Fitting Type	N/A
Transmission Oil Cooler Included	No
Radiator Cap Included	No
Inlet Location	Top Left
Core Finish	Uncoated
Drain Plug Included	Yes
Fluid Capacity	7.94
TechSpec Overall Height (in)	22
TechSpec Overall Length (in)	33.5
TechSpec Overall Width (in)	2.75
TechSpec Core Length (in)	26.75
TechSpec Core Height (in)	22
TechSpec Fluid Capacity (gal)	8
TechSpec Rows	3
TechSpec Inlet (in)	1.61
TechSpec Outlet (in)	1.61
TechSpec Core Thickness (in)	1.88
TechSpec Drain Plug Thread Size	M12 x 1.5
TechSpec DPI	N/A
TechSpec Material	Aluminum
TechSpec Applications	Ram 2500 6.7L L6 2013-2018--Ram 3500 6.7L L6 2013-2018--Ram 4500 6.7L L6 2013-2018--Ram 5500 6.7L L6 2013-2018
TechSpec Engine Codes	N/A
TechSpec Chassis Codes	N/A
TechSpec Note	N/A
TechSpec Includes	Mishimoto Radiator--Magnetic Drain Plug--(2) Transmission Cooler Fittings-- M6 x 1.0 - 16mm Bolt--(3) M6 x 1.0 - 14mm Bolts--(4) M6 x 1.0 - 12mm Bolts--(3) M6 Flat Washers--Mishimoto Lifetime Warranty
SellingPoint01	Direct fit for the 2013-2018 Dodge Ram 6.7L Cummins
SellingPoint02	Increases coolant capacity by 63-percent and surface area by 41-percent to maximize cooling
SellingPoint03	Durable fully aluminum construction with TIG-welded end tanks and fittings
SellingPoint04	Features a 2-in thick, three-row core for efficient cooling under high loads
SellingPoint05	Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system
SellingPoint06	Mishimoto Lifetime Warranty
SellingPoint07	N/A
SellingPoint08	N/A
SellingPoint09	N/A
SellingPoint10	N/A
SellingPoint11	N/A
SellingPoint12	N/A
SellingPoint13	N/A
SellingPoint14	N/A
SellingPoint15	N/A
Install Difficulty	5
