Mishimoto MMRAD-TAC-24 Performance Aluminum Radiator, fits Toyota Tacoma 2024+

$799.95 USD

Sale Sold out

Shipping calculated at checkout.

Low stock: 2 left

Description & Features

Mishimoto MMRAD-TAC-24 Performance Aluminum Radiator, fits Toyota Tacoma 2024+

Keep your 2024+ Toyota Tacoma cool and dependable on every drive with a radiator built for strength and endurance. The Mishimoto Performance Aluminum Radiator replaces the stock plastic unit with a fully TIG-welded aluminum design that eliminates weak points and provides reliable performance under tough conditions. A uniquely engineered mounting bracket system, proven through internal vibration testing, delivers exceptional resistance to chassis flex and off-road abuse. -- Internal strutted tubes strengthen the core to prevent fatigue over time while a 46% increase in core volume and 23% greater fluid capacity improve heat dissipation and overall cooling efficiency. The built-in 7-row stacked plate transmission cooler outperforms the stock tube-style design, providing superior control of transmission temperatures when towing, off-roading, or running heavier aftermarket parts. -- Every detail is crafted for long-term reliability. The increased coolant capacity improves thermal stability, while the magnetic drain plug captures debris to help protect the cooling system. Whether you're heading into the mountains or navigating daily traffic, this radiator ensures consistent performance and lasting durability, all backed by the Mishimoto Lifetime Warranty.

All-aluminum construction with TIG-welded end tanks for maximum strength and leak-free reliability
46% increase in core volume and 23% greater fluid capacity for superior heat management
Upgraded mounting bracket system tested for resistance to vibration

Specifications

Fluid Capacity	0
Inlet Diameter	1.3
Outlet Diameter	1.3
Core Thickness	1.6
Core Length	24.4
Core Height	27.8
Overall Height	28.9
Overall Length	31.6
Overall Width	5.4
Core Material	Aluminum
Down Flow Or Cross Flow Type	Cross Flow
Drain Plug Thread Size	M12 - 1.5
Transmission Oil Cooler Fitting Type	N/A
Radiator Cap Included	No
Outlet Location	Right
Inlet Location	Top Left
Core Finish	Uncoated
Drain Plug Included	Yes
Transmission Oil Cooler Included	Yes
Core Row Quantity	7
TechSpec Chassis Codes	N/A
TechSpec Note	Does not fit TRD Pro, Trailhunter, or Tacoma trucks optioned with the i-Force Max hybrid engine
TechSpec Includes	N/A
Install Difficulty	3
SellingPoint01	All-aluminum construction with TIG-welded end tanks for maximum strength and leak-free reliability
SellingPoint02	46% increase in core volume and 23% greater fluid capacity for superior heat management
SellingPoint03	Upgraded mounting bracket system tested for resistance to vibration
SellingPoint04	Internal strutted tubes strengthen the core to resist chassis flex when towing and off-roading
SellingPoint05	7-row stacked plate in-tank transmission cooler provides improved cooling capabilities over stock
SellingPoint06	Included magnetic drain plug helps capture debris to extend the life of the cooling system
SellingPoint07	Designed to support the added demands of larger tires, lifts, and extra accessories
SellingPoint08	Mishimoto Lifetime Warranty
SellingPoint09	N/A
SellingPoint10	N/A
SellingPoint11	N/A
SellingPoint12	N/A
SellingPoint13	N/A
SellingPoint14	N/A
SellingPoint15	N/A
TechSpec Overall Height (in)	28.9
TechSpec Overall Length (in)	31.6
TechSpec Overall Width (ins)	5.4
TechSpec Core Length (in)	24.4
TechSpec Core Height (in)	27.8
TechSpec Fluid Capacity (gal)	N/A
TechSpec Rows	N/A
TechSpec Inlet (in)	1.3
TechSpec Outlet (in)	1.3
TechSpec Core Thickness (in)	1.6
TechSpec Drain Plug Thread Size	M12x1.5
TechSpec DPI	N/A
TechSpec Material	Aluminum
TechSpec Applications	Toyota Tacoma Limited 2.4 L4 2024-2025--Toyota Tacoma SR 2.4 L4 2024-2025--Toyota Tacoma SR5 2.4 L4 2024-2025--Toyota Tacoma TRD Off-Road 2.4 L4 2024-2025--Toyota Tacoma TRD PreRunner 2.4 L4 2024-2025--Toyota Tacoma TRD Sport 2.4 L4 2024-2025
TechSpec Engine Codes	N/A
