TrakMotive CH-8119 CV Axle Shaft
TrakMotive CH-8119 CV Axle Shaft
Regular price
$106.34 USD
Regular price
$114.52 USD
Sale price
$106.34 USD
⬡Mechanic Division pricing available
Shipping calculated at checkout.
10 in stock
Quantity
Couldn't load pickup availability
Description & Features
TrakMotive CH-8119 CV Axle Shaft
TrakMotive's CH-8119 is a Premium-grade CV axle shaft engineered as a direct OE replacement, fitting either the front-left or front-right position. Fits 2006-2010 Dodge Ram 1500 and 2011 Ram 1500.
- Premium grade — OE replacement CV axle
- Fits either front-left or front-right position
- Fits 2006-2010 Dodge Ram 1500, 2011 Ram 1500
Specifications
| ABS Tone Ring Included | No |
| Axle Nut Height (in) | 1 |
| Axle Nut Hex Size (in) | 1.4 |
| Axle Nut Length (mm) | 41 |
| Grade Type | Premium |
| Number Of Bolt Holes | 0 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Outboard Joint Type | Conventional |
| Axle Nut Hex Size (mm) | 36 |
| Axle Nut Locking Type | Self-Lock |
| Inboard Joint Boot Material | Neoprene |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Outboard Shaft Connection Style | Conventional |
| ABS Ring Tooth Count | 0 |
| Axle Nut Head Type | Hex |
| Axle Nut Height (mm) | 23 |
| Axle Nut Included | Yes |
| Axle Nut Socket Size | 36 |
| Inboard Joint Type | Female |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 33 |
| Overall Compressed Length (in) | 23.74 |
| Axle Nut Length (in) | 1.6 |
| Axle Nut Thread Size | M24x2 |
| Inboard Shaft Connection Style | Female |
| Number Of Inboard Splines | 29 |
| Outboard Joint Boot Material | Neoprene |
| Overall Compressed Length (mm) | 603 |
Share
No reviews
Vehicle Fitment
Vehicle Fitment
- 2006-2010 DODGE RAM 1500 — Front Left
- 2006-2010 DODGE RAM 1500 — Front Right
- 2011 RAM 1500 — Front Left
- 2011 RAM 1500 — Front Right
